Product introduction
Fiber optical taper (FOT) is prepared by reheating and drawing the rough FOP. FOT can zoom in or out the image, which can couple the image intensifier with CCD to realize digital processing on image. FOT is widely used in night vision, medical treatment, image coupling and other fields. According to user requirements, shape, cone ratio, size, fiber diameter can be customized.
Single-fiber diameter：Φ4~12μm
Effective aperture：Φ8~100mm
Coefficient of expansion：（60~90）×10-7/℃
numerical aperture：NA≥1
Shear distortion: ＜30μm
Gross distortion: ≤有效直径的0.5%(0.5% of effective aperture)
Frame run-out：≤200μm
Spot: ≤90μm
More product specifications and performance can be customized according to user requirements.
